Precise Density Measurement for Reliable Level Indication
Experience highest measurement accuracy with WEKA floats operating on the proven rod magnet principle. Each float is precisely calibrated to the density of your measurement liquid, ensuring that the integrated rod magnet is positioned exactly at the liquid surface level. The innovative design guarantees reliable function even under the most extreme operating conditions.
Floats

Innovative Rod Magnet Principle for Highest Precision
Each WEKA float is precisely calibrated to the density of your measurement liquid, ensuring that the integrated rod magnet is positioned exactly at the liquid surface level. The magnetic field acts with the north pole on the indicator flags and with the south pole on optional accessories such as magnetic switches or level transmitters.
The low weight of the rod magnet principle enables lightweight construction with maximum radial clearance to the standpipe – ideal for contaminated or viscous media. Selected magnetic materials ensure reliable function even at extreme operating temperatures up to 400°C.
| Type | Max. Pressure | Density | Diameter |
| Cylinder Floats | ≥60 bar/ open | ≥1.2 | 26/42/47mm |
| Ball Floats | ≥230bar | ≥1.19 | 28/45/48/62mm |
| Cylinder Floats - Plastic | ≥20 bar | ≥1.15 | 27/28,5/32,5/46/50mm |
| Special Floats | ≥60 bar | ≥1.2 | 25/42/47 mm |
| Ball Floats with Reflection Plate | ≥100 bar | ≥0.45 | 45/48/62mm |
| All floats: Temperature up to +400°C, lightweight rod magnet principle |
Cylinder Floats
Application:
Standard applications in various media
Design:
Cylindrical geometry for optimal guidance
Material:
Various materials according to media requirements
Advantage:
Proven, reliable construction
Ball Floats
Application:
Special applications with particular requirements
Design:
Spherical geometry
Properties:
Compact construction
Specialty:
Optimized for specific media densities
Cylinder Floats - Plastic
Application:
Corrosive media and food industry
Material:
High-quality plastics
Advantage:
Chemical resistance and low weight
Application Area:
Aggressive chemicals, food products
Special Floats
Application:
Customer-specific special applications
Design:
According to individual requirements
Flexibility:
Adaptation to special media properties
Development:
Tailor-made solutions
Ball Floats with Reflection Plate
Application:
Extended optical display functions
Specialty:
Integrated reflection plate
Function:
Improved visibility and readability
Advantage:
Optimized visual control
This product is frequently used in the following areas:
